Products

  • Fieldbus Open loop Stepper Drive ECR Series

    Fieldbus Open loop Stepper Drive ECR Series

    The EtherCAT fieldbus stepper drive is based on the CoE standard framework and complies with the CiA402 standard. The data transmission rate is up to 100Mb/s, and supports various network topologies.

    ECR42 matches open loop stepper motors below 42mm.

    ECR60 matches open loop stepper motors below 60mm.

    ECR86 matches open loop stepper motors below 86mm.

    •  Control mode: PP, PV, CSP, HM, etc

    •  Power supply voltage: 18-80VDC (ECR60), 24-100VDC/18-80VAC (ECR86)

    •  Input and output: 2-channel differential inputs/4-channel 24V common anode inputs; 2-channel optocoupler isolated outputs

    •  Typical applications: assembly lines, lithium battery equipment, solar equipment, 3C electronic equipment, etc

  • Fieldbus Closed loop Stepper Drive ECT Series

    Fieldbus Closed loop Stepper Drive ECT Series

    The EtherCAT fieldbus stepper drive is based on the CoE standard framework and complies with the CiA402

    standard. The data transmission rate is up to 100Mb/s, and supports various network topologies.

    ECT42 matches closed loop stepper motors below 42mm.

    ECT60 matches closed loop stepper motors below 60mm.

    ECT86 matches closed loop stepper motors below 86mm.

    •  ontrol mode: PP, PV, CSP, HM, etc

    •  Power supply voltage: 18-80VDC (ECT60), 24-100VDC/18-80VAC (ECT86)

    •  Input and output: 4-channel 24V common anode input; 2-channel optocoupler isolated outputs

    •  Typical applications: assembly lines, lithium battery equipment, solar equipment, 3C electronic equipment, etc

  • Fieldbus Open loop Stepper Drive ECT60X2

    Fieldbus Open loop Stepper Drive ECT60X2

    The EtherCAT fieldbus open loop stepper drive ECT60X2 is based on the CoE standard framework and complies with the CiA402 standard. The data transmission rate is up to 100Mb/s, and supports various network topologies.

    ECT60X2 matches open loop stepper motors below 60mm.

    •  Control modes: PP, PV, CSP, CSV, HM, etc

    •  Power supply voltage: 18-80V DC

    •  Input and output: 8-channel 24V common positive input; 4-channel optocoupler isolation outputs

    •  Typical applications: assembly lines, lithium battery equipment, solar equipment, 3C electronic equipment, etc

  • Fieldbus Stepper Drive NT60

    Fieldbus Stepper Drive NT60

    485 fieldbus stepper drive NT60 is based on RS-485 network to run Modbus RTU protocol. The intelligent motion control

    function is integrated, and with external IO control, it can complete functions such as fixed position/fixed speed/multi

    position/auto-homing

    NT60 matches open loop or closed loop stepper motors below 60mm

    •   Control mode: fixed length/fixed speed/homing/multi-speed/multi-position

    •  Debugging software: RTConfigurator (multiplexed RS485 interface)

    •  Power voltage: 24-50V DC

    •  Typical applications: single axis electric cylinder, assembly line, connection table, multi-axis positioning platform, etc

  • Advanced Fieldbus Digital Stepper Drive NT86

    Advanced Fieldbus Digital Stepper Drive NT86

    485 fieldbus stepper drive NT60 is based on RS-485 network to run Modbus RTU protocol. The intelligent motion control

    function is integrated, and with external IO control, it can complete functions such as fixed position/fixed speed/multi

    position/auto-homing.

    NT86 matches open loop or closed loop stepper motors below 86mm.

    •  Control mode: fixed length/fixed speed/homing/multi-speed/multi-position/potentiometer speed regulation

    •  Debugging software: RTConfigurator (multiplexed RS485 interface)

    •  Power voltage: 18-110VDC, 18-80VAC

    •  Typical applications: single axis electric cylinder, assembly line, multi-axis positioning platform, etc

  • Modbus TCP Open loop Stepper Drive EPR60

    Modbus TCP Open loop Stepper Drive EPR60

    The Ethernet fieldbus-controlled stepper drive EPR60 runs the Modbus TCP protocol based on standard Ethernet interface and integrates a rich set of motion control functions. EPR60 adopts standard 10M/100M bps network layout, which is convenient to build the Internet of Things for automation equipment

    EPR60 is compatible with open-loop stepper motors base below 60mm.

    •  Control mode: fixed length/fixed speed/homing/multi-speed/multi-position

    •  Debugging software: RTConfigurator (USB interface)

    •  Power voltage: 18-50VDC

    •  Typical applications: assembly lines, warehousing logistics equipment, multi-axis positioning platforms, etc

    •  Closed-loop EPT60 is optional

  • Fieldbus Open loop Stepper Drive ECR60X2A

    Fieldbus Open loop Stepper Drive ECR60X2A

    The EtherCAT fieldbus open loop stepper drive ECR60X2A is based on the CoE standard framework and complies with the CiA402 standard. The data transmission rate is up to 100Mb/s, and supports various network topologies.

    ECR60X2A matches open loop stepper motors below 60mm.

    •  Control modes: PP, PV, CSP, CSV, HM, etc

    •  Power supply voltage: 18-80V DC

    •  Input and output: 8-channel 24V common positive input; 4-channel optocoupler isolation outputs

    •  Typical applications: assembly lines, lithium battery equipment, solar equipment, 3C electronic equipment, etc
